Unbound Views in OPNsense to Resolve Domains by VLAN/Subnet

Configure Unbound DNS in OPNsense for Subnet Based Domain Resolution

Running multiple VLANs in your home or lab can be a headache — especially when it comes to DNS. If you’ve got a server with interfaces on multiple VLANs/subnets, OPNsense’s Unbound DNS doesn’t respond automatically based on the interface or subnet. By default, it gives clients all the IPs it knows for that hostname.

That means your gaming PC on VLAN 112 might resolve unraid.myhouse.home.arpa to an IP on VLAN 88, which won’t work.


Unbound Views

Unbound has a feature called views. With views, you can tell Unbound:

  • “If a client comes from subnet 192.168.112.0/21, use this view.”

  • “If a client comes from subnet 192.168.88.0/21, use that view.”

Each view can have its own DNS records, so the same hostname can return different IPs depending on the source VLAN.

For example:

  • Clients on VLAN 112 → unraid.myhouse.home.arpa = 192.168.112.12

  • Clients on VLAN 88 → unraid.myhouse.home.arpa = 192.168.88.12

This solves DNS leaking all IPs problem once and for all.


Unbound Views Script

If you only have one or two VLANs, you could hand-write the Unbound config file with views. But if you’ve got multiple VLANs and several hosts, the config quickly becomes tedious and error-prone.

That’s why I built a script to do it automatically. Instead of learning Unbound’s config syntax line-by-line, you just define your VLANs and hosts in a simple text file — and the script generates the correct configuration for OPNsense.

You can find the — 🔭 generate-unbound-views.sh script — script below.


Using DNS Views

When running multiple VLANs and subnets in OPNsense, you may need Unbound DNS to return different IP addresses depending on the interface or client network.

For example:

  • You have a host unraid with addresses on multiple VLANs.

  • You want clients on VLAN 112 (192.168.112.0/21) to resolve unraid.myhouse.home.arpa to 192.168.112.12.

  • You want clients on VLAN 88 (192.168.88.0/21) to resolve that same hostname to 192.168.88.12.

By default, OPNsense/Unbound will happily return all addresses for unraid to everyone — which isn’t what we want.

This is where views come in. PowerDNS, some CISCO stuff, and BIND all have views available. Infact, BIND introduced views. BIND is available in OPNsense, but today we’re just covering Unbound.


The Problem with Old Documentation

If you’ve searched forums or blogs, you’ve probably seen instructions like:

“Paste your custom config under Services → Unbound DNS → Advanced.”

That’s no longer possible. As of OPNsense 21.1, the custom configuration fields were removed (announcement here).

New Production Friendly Method

The new approach is to place your Unbound config snippets into:

1
/usr/local/etc/unbound.opnsense.d/

That’s documented in the OPNsense manual, but it doesn’t explain how to use Unbound views.For that, you need the upstream Unbound docs:


Step-by-Step: Configuring Views

We’re going to tell Unbound:

  • Which subnets belong to which views

  • What local records each view should return


Instructions will walk through setting this up with two VLANs:

  • VLAN 112: 192.168.112.0/21unraid = 192.168.112.12

  • VLAN 88: 192.168.88.0/21unraid = 192.168.88.12


1. SSH into OPNsense and install an editor

1
pkg install nano

2. Create a custom Unbound config file

1
nano /usr/local/etc/unbound.opnsense.d/vlan-views.conf

3. Add the configuration

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
# Server defines which subnets use which views
server:
    access-control-view: 192.168.112.0/21 "vlan112_view"
    access-control-view: 192.168.88.0/21 "vlan88_view"

# View for VLAN 112 (Gaming)
view:
    name: "vlan112_view"
    local-zone: "myhouse.home.arpa." transparent
    local-data: "unraid.myhouse.home.arpa. IN A 192.168.112.12"

# View for VLAN 88 (Work)
view:
    name: "vlan88_view"
    local-zone: "myhouse.home.arpa." transparent
    local-data: "unraid.myhouse.home.arpa. IN A 192.168.88.12"

🔎 Replace myhouse.home.arpa with your own local domain.

4. Validate the config

1
configctl unbound check

5. Restart Unbound

1
configctl unbound restart

(Optional: reboot if you want to be extra sure it persists.)

6. Verify

The config won’t appear in /var/unbound/unbound.conf directly — that file is generated dynamically. But your custom file will be included automatically.

Check with:

1
2
dig @192.168.112.254 unraid.myhouse.home.arpa
dig @192.168.88.254 unraid.myhouse.home.arpa

Clients in VLAN 112 should get 192.168.112.12, while VLAN 88 clients should get 192.168.88.12.


Now you can:

  • Control DNS responses per subnet/VLAN

  • Keep multiple interfaces for the same hostname cleanly separated

  • Avoid Unbound’s default behavior of returning all addresses

This is extremely useful if you’re running a host that has multiple IPs across different networks, but you want clients to resolve to the “closest” or correct one automatically.


Automating Unbound Views with a Script

Doing this by hand works fine for one or two VLANs. But if you have several VLANs and multiple hosts (unraid, nas, plex…), editing configs quickly becomes painful.

That’s why I wrote a script — 🔭 generate-unbound-views.sh script — that automates everything.


How It Works

The script takes an input file where each line is:

VLAN_ID,SUBNET,HOSTNAME,IP_ADDRESS

For example:

# Gaming VLAN
112,192.168.112.0/21,unraid,192.168.112.12
112,192.168.112.0/21,nas,192.168.112.15

# Work VLAN
88,192.168.88.0/21,unraid,192.168.88.12
88,192.168.88.0/21,nas,192.168.88.15

Run the script, and it generates the full Unbound config.


Running the Script

Step 1. Download the generate-unbound-views.sh script

Copy and paste the script to your OPNsense box, adding execute privs:

1
2
nano /root/generate-unbound-views.sh
chmod +x /root/generate-unbound-views.sh

Step 2. VLAN_ID,SUBNET,HOSTNAME,IP_ADDRESS

Create your VLAN definitions in a file:

1
nano /root/vlans.txt

Step 3. Use the script and your input file

Generate the Unbound config:

1
./generate-unbound-views.sh vlans.txt /usr/local/etc/unbound.opnsense.d/vlan-views.conf

Step 4. Does it still work

Validate and restart Unbound:

1
2
configctl unbound check
configctl unbound restart

Step 5. Did you change anything

Test resolution from each VLAN:

1
dig unraid

Clients on VLAN 112 will see the .112.12 address, while VLAN 88 clients will see .88.12.


generate-unbound-views.sh script

Remember: Put all of your VLANs, Subnets, hostnames, IPs in a simple comma seperated text file for input.


1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
#!/bin/sh
#
# generate-unbound-views.sh
#
# Purpose: Generate Unbound VLAN-specific DNS views configuration from an input file
# Usage: ./generate-unbound-views.sh input.txt output.conf
#
# Input file format (CSV-style, comments allowed with #):
# VLAN_ID,SUBNET,HOSTNAME,IP_ADDRESS
#
# Example input.txt:
# # Gaming VLAN
# 112,192.168.112.0/24,unraid,192.168.112.12
# 112,192.168.112.0/24,nas,192.168.112.15
# # Work VLAN
# 88,192.168.88.0/24,unraid,192.168.88.12
# 88,192.168.88.0/24,nas,192.168.88.15

set -e  # Exit on any error

# ============================================================================
# Configuration
# ============================================================================
DOMAIN_SUFFIX="myhouse.home.arpa"
DEFAULT_OUTPUT="/usr/local/etc/unbound.opnsense.d/vlan-views.conf"

# ============================================================================
# Functions
# ============================================================================

usage() {
    cat << EOF
Usage: $0 <input_file> [output_file]

Generate Unbound VLAN-specific DNS views configuration.

Arguments:
    input_file   - CSV file with VLAN definitions (required)
    output_file  - Output configuration file (default: ${DEFAULT_OUTPUT})

Input file format (CSV with optional comments):
    VLAN_ID,SUBNET,HOSTNAME,IP_ADDRESS

Example input file:
    # Gaming VLAN
    112,192.168.112.0/24,unraid,192.168.112.12
    112,192.168.112.0/24,nas,192.168.112.15
    # Work VLAN
    88,192.168.88.0/24,unraid,192.168.88.12
    88,192.168.88.0/24,nas,192.168.88.15

Example usage:
    $0 vlans.txt
    $0 vlans.txt /tmp/test-views.conf

After generation:
    configctl unbound check    # Validate configuration
    configctl unbound restart  # Apply changes
EOF
    exit 1
}

log_info() {
    echo "[INFO] $*" >&2
}

log_error() {
    echo "[ERROR] $*" >&2
}

validate_input() {
    local input_file="$1"

    if [ ! -f "$input_file" ]; then
        log_error "Input file not found: $input_file"
        exit 1
    fi

    if [ ! -r "$input_file" ]; then
        log_error "Input file not readable: $input_file"
        exit 1
    fi

    # Check if file has any valid data lines
    if ! grep -qE '^[^#]' "$input_file" 2>/dev/null; then
        log_error "Input file contains no valid data (only comments or empty)"
        exit 1
    fi
}

# ============================================================================
# Main Script
# ============================================================================

# Check arguments
if [ $# -lt 1 ]; then
    usage
fi

INPUT_FILE="$1"
OUTPUT_FILE="${2:-$DEFAULT_OUTPUT}"

log_info "Input file: $INPUT_FILE"
log_info "Output file: $OUTPUT_FILE"
log_info "Domain suffix: $DOMAIN_SUFFIX"

# Validate input file
validate_input "$INPUT_FILE"

# Create temporary file for processing
TMP_FILE=$(mktemp) || {
    log_error "Failed to create temporary file"
    exit 1
}

# Ensure temp file cleanup on exit
trap 'rm -f "$TMP_FILE"' EXIT INT TERM

# ============================================================================
# Parse input and build data structures
# ============================================================================
log_info "Parsing input file..."

# Arrays to store unique VLANs and their data
# Format: vlan_id:subnet:hostname1:ip1:hostname2:ip2...
VLAN_DATA=""

while IFS=',' read -r vlan_id subnet hostname ip_address; do
    # Skip comments and empty lines
    echo "$vlan_id" | grep -qE '^\s*#' && continue
    echo "$vlan_id" | grep -qE '^\s*$' && continue

    # Trim whitespace
    vlan_id=$(echo "$vlan_id" | tr -d ' \t')
    subnet=$(echo "$subnet" | tr -d ' \t')
    hostname=$(echo "$hostname" | tr -d ' \t')
    ip_address=$(echo "$ip_address" | tr -d ' \t')

    # Validate fields
    if [ -z "$vlan_id" ] || [ -z "$subnet" ] || [ -z "$hostname" ] || [ -z "$ip_address" ]; then
        log_error "Invalid line (missing fields): $vlan_id,$subnet,$hostname,$ip_address"
        continue
    fi

    # Store data - append to existing VLAN or create new entry
    if echo "$VLAN_DATA" | grep -q "^$vlan_id:$subnet:"; then
        # Append to existing VLAN
        VLAN_DATA=$(echo "$VLAN_DATA" | sed "s|^$vlan_id:$subnet:\(.*\)$|$vlan_id:$subnet:\1:$hostname:$ip_address|")
    else
        # New VLAN entry
        if [ -z "$VLAN_DATA" ]; then
            VLAN_DATA="$vlan_id:$subnet:$hostname:$ip_address"
        else
            VLAN_DATA="$VLAN_DATA
$vlan_id:$subnet:$hostname:$ip_address"
        fi
    fi

done < "$INPUT_FILE"

if [ -z "$VLAN_DATA" ]; then
    log_error "No valid data parsed from input file"
    exit 1
fi

# ============================================================================
# Generate configuration file
# ============================================================================
log_info "Generating Unbound configuration..."

cat > "$TMP_FILE" << 'EOF_HEADER'
# Unbound VLAN-specific DNS Views Configuration
# Generated by generate-unbound-views.sh
# DO NOT EDIT MANUALLY - Regenerate using the script
#
# Purpose: Return VLAN-specific IP addresses based on which subnet
# the DNS query originates from.

# ============================================================================
# SERVER CLAUSE
# ============================================================================
# CRITICAL: access-control-view MUST be inside a server: clause.
# These directives are server-level configuration and will be ignored or
# cause errors if placed at the root level of the config file.
server:
    # Map source subnets to their respective views
    # Format: access-control-view: <subnet> "<view_name>"
    # Note: View names MUST be quoted

EOF_HEADER

# Generate access-control-view entries
echo "$VLAN_DATA" | while IFS=':' read -r vlan_id subnet rest; do
    cat >> "$TMP_FILE" << EOF
    # VLAN ${vlan_id} - ${subnet}
    access-control-view: ${subnet} "vlan${vlan_id}_view"

EOF
done

cat >> "$TMP_FILE" << 'EOF_MID'

# ============================================================================
# VIEWS - One per VLAN
# ============================================================================
EOF_MID

# Generate view entries
echo "$VLAN_DATA" | while IFS= read -r line; do
    [ -z "$line" ] && continue

    # Extract vlan_id and subnet (first two colon-separated fields)
    vlan_id=$(echo "$line" | cut -d: -f1)
    subnet=$(echo "$line" | cut -d: -f2)

    cat >> "$TMP_FILE" << EOF

# ============================================================================
# VIEW FOR VLAN ${vlan_id}
# ============================================================================
# Subnet: ${subnet}
# A view is a named local-zone tree that can be assigned to specific clients.
view:
    # Unique name for this view (must match access-control-view above)
    name: "vlan${vlan_id}_view"

    # Local zone type: "transparent"
    # - transparent: Answers local-data queries here, allows other queries to
    #   resolve normally (e.g., DHCP registrations, other host overrides)
    # - static: Would ONLY answer from local-data defined here; everything
    #   else would get NXDOMAIN (too restrictive for most use cases)
    local-zone: "${DOMAIN_SUFFIX}." transparent

    # A records for this VLAN
EOF

    # Parse and add all hostnames for this VLAN
    # Format: vlan:subnet:hostname1:ip1:hostname2:ip2...
    # Start from field 3 (after vlan and subnet)
    field_num=3
    num_fields=$(echo "$line" | awk -F: '{print NF}')

    while [ $field_num -le $num_fields ]; do
        hostname=$(echo "$line" | cut -d: -f${field_num})
        next_field=$((field_num + 1))

        if [ $next_field -le $num_fields ]; then
            ip=$(echo "$line" | cut -d: -f${next_field})

            if [ -n "$hostname" ] && [ -n "$ip" ]; then
                cat >> "$TMP_FILE" << EOF
    local-data: "${hostname}.${DOMAIN_SUFFIX}. IN A ${ip}"
EOF
            fi
        fi

        # Move to next pair (skip 2 fields: hostname and ip)
        field_num=$((field_num + 2))
    done

    echo "" >> "$TMP_FILE"
done

# Add footer with instructions
cat >> "$TMP_FILE" << 'EOF_FOOTER'

# ============================================================================
# VALIDATION & RESTART
# ============================================================================
# After editing the input file and regenerating:
# 1. Validate: configctl unbound check
# 2. Restart:  configctl unbound restart
# 3. Test:     nslookup <hostname>.<domain> (from each VLAN)
#
# To regenerate this file, edit your input file and run:
#     ./generate-unbound-views.sh <input_file>
# ============================================================================
EOF_FOOTER

# ============================================================================
# Install the configuration
# ============================================================================

# Check if output directory exists
OUTPUT_DIR=$(dirname "$OUTPUT_FILE")
if [ ! -d "$OUTPUT_DIR" ]; then
    log_error "Output directory does not exist: $OUTPUT_DIR"
    log_error "This script is intended for OPNsense with Unbound installed"
    exit 1
fi

# Backup existing file if it exists
if [ -f "$OUTPUT_FILE" ]; then
    BACKUP_FILE="${OUTPUT_FILE}.backup.$(date +%Y%m%d_%H%M%S)"
    log_info "Backing up existing configuration to: $BACKUP_FILE"
    cp "$OUTPUT_FILE" "$BACKUP_FILE"
fi

# Move temp file to final location
mv "$TMP_FILE" "$OUTPUT_FILE"
chmod 644 "$OUTPUT_FILE"

log_info "Configuration generated successfully: $OUTPUT_FILE"
log_info ""
log_info "Next steps:"
log_info "  1. Review the configuration: cat $OUTPUT_FILE"
log_info "  2. Validate: configctl unbound check"
log_info "  3. Apply: configctl unbound restart"
log_info ""

# Summary of what was generated
VLAN_COUNT=$(echo "$VLAN_DATA" | wc -l | tr -d ' ')
log_info "Summary:"
log_info "  - VLANs configured: $VLAN_COUNT"
log_info "  - Domain suffix: $DOMAIN_SUFFIX"

echo "$VLAN_DATA" | while IFS=':' read -r vlan_id subnet rest; do
    # Count hostnames (every other field after subnet)
    host_count=$(echo "$rest" | awk -F: '{print int((NF+1)/2)}')
    log_info "  - VLAN $vlan_id ($subnet): $host_count host(s)"
done

exit 0

This post is licensed under CC BY 4.0 by the author.
