Homelab Guide to Monitoring Docker Logs and Log Files

When you’re running containerized applications, you need to understand what’s happening inside your stack.

This article was written to help you get better understanding of logging and observability.

If you want to try this out yourself on system prepared for you, check out the free labs available for Grafana at killercoda.com.

Homelab Monitoring Stack: Alloy, Loki, and Grafana

This article uses three tools for monitoring:

Grafana Alloy for log collection
Loki for log storage
Grafana for visualization

By the end of this guide, you’ll understand what each part does.

BONUS: Traefik is also used in this stack.

What Is Alloy?

Alloy is Grafana’s modern log collector. It is replacing Promtail, for Alloy’s OTEL support.

Think of it as building pipelines with three stages:

Pull Data - Discover and collect logs
Process Data - Parse, label, and transform
Send Data - Forward to destinations

Important Syntax Gotchas:

Alloy uses HCL (HashiCorp Configuration Language)
Comments use // not #
Commas, even after the last item in the list

What Is Loki?

Loki is Grafana’s log aggregation system. It’s designed to be a way to store your losts, cost-effective and easy to operate.

Unlike traditional log systems, Loki doesn’t index log content. Instead:

Index Labels Only - Stores metadata like service name, host, job
Compress Logs - Keeps raw log lines compressed

Key Design Principles:

Only label dimensions you’ll query by (service, environment, host)
Don’t add high-cardinality labels (user IDs, request IDs, timestamps)
Use LogQL to filter log content at query time
Logs are stored in chunks and kept in object storage

Storage Modes:

filesystem - Simple, good for single-node setups
s3 or gcs - Production-ready, scalable storage

What Is Grafana?

Grafana is your visualization dashboard. It queries Loki (and other data sources) to display logs, metrics, and handles alerts all in one place.

Key concepts:

Data Sources - Connect to Loki, Prometheus, etc.
Dashboards - Visual panels showing your data

Part 1: Alloy Reads - Docker Socket Logs

Alloy is the first step, it allows us to take a log file, or a unix socket, read from it, and transform it, before sending it off for log ingestion and storage.

1). Alloy Access to Docker Socket

First, to get Alloy to read all the logs in docker, you must give it access to the docker socket.

You can add the Alloy container to the docker socket in your docker-compose.yml file using a volume mount.

Here’s how to modify your docker-compose.yml:


alloy:
  image: grafana/alloy:latest
  volumes:
    - "/var/run/docker.sock:/var/run/docker.sock:ro"

Don’t forget to also mount the Docker socket (/var/run/docker.sock) as a read-only volume so Alloy can only access Docker’s API to read container logs.

2). Get Alloy to Discover Docker Containers

Let’s look at how reading docker logs works in our config.alloy file.

In the config.alloy file, we will start with container discovery.

The Docker socket is a Unix socket that allows processes to communicate with the Docker daemon, and Alloy uses this to discover all running containers on your system.

Here’s the discovery block:


// Discover running Docker containers
discovery.docker "containers" {
    host = "unix:///var/run/docker.sock"
}

This connects to Docker and discovers all running containers.

The exported field discovery.docker.containers.targets contains the list of discovered containers.

This is also only possible because of our docker-compose.yml file, where we mount the Docker socket into the Alloy container.

You can now view the list of all of your targets and their fields in Alloy:

Access it on the Alloy Web UI: http://your-alloy-host:12345/component/discovery.docker.containers

Grafana Alloy Docker Discovery Documentation

3). Use Alloy to Clean Up Labels

Discovering containers is only the first step.

We need to transform the raw metadata that Docker provides into useful labels that we can query later.

This is where the relabeling process comes in.

Grafana Alloy’s discovery.relabel block takes the raw Docker metadata and creates structured labels. For example, Docker provides the container name as __meta_docker_container_name with a leading slash, like (/traefik). Let’s fix that, it’s easier to refer to contianers with the / removed:


discovery.relabel "containers" {
    targets = discovery.docker.containers.targets

    rule {
        source_labels = ["__meta_docker_container_name"]
        regex         = "/(.*)"
        target_label  = "container"
    }
}

Each rule block transforms labels, meaning, each rule transforms Docker’s internal metadata into labels you can actually use when searching logs. The regex pattern /(.*) captures everything after the leading slash, it strips the leading slash, giving us clean container names. Then the exported field is discovery.relabel.containers.output.

You can now view the list of all of your new target_labels and their fields in Alloy (they will be at the bottom):

Access it: http://your-alloy-host:12345/component/discovery.relabel.containers#Arguments-rule_0

Grafana Alloy Discovery Relabeling

4). Finish Step 3

Now that you understand the concept, let’s clean up the rest of those fields and make them all presentable.


// Add proper labels to discovered containers
discovery.relabel "containers" {
    targets = discovery.docker.containers.targets

// You should already have this rule in, add the ones under it
    rule {
        source_labels = ["__meta_docker_container_name"]
        regex         = "/(.*)"
        target_label  = "container"
    }
    rule {
        source_labels = ["__meta_docker_container_log_stream"]
        target_label  = "stream"
    }
    rule {
        source_labels = ["__meta_docker_container_id"]
        target_label  = "container_id"
    }
}

This block accepts the list of discovered Docker targets from the previous component (discovery.docker.containers.targets).

Docker setups with Promtail (now Alloy) often export the label, container, as it is a longstanding convention for the raw container name (e.g., “Plex”),

But, service_name is gaining traction for Kubernetes or multi-service setups.

You will see both container and service_name labels from __meta_docker_container_name. This is for maximum Grafana dashboard compatability.

This ensures your logs arrive in Loki/Grafana with standard, readable tags like container and container_id rather than obscure internal variables.

Put a Filter in Your Rules (optional)

This is an example. If you had a container you didnt want to include in the logs, you can add a rule to drop specific containers.


rule {
  source_labels = ["__meta_docker_container_name"]
  regex         = "noisy_container_.*"
  action        = "drop"
}

5). Alloy Send Logs to Collector

Finally, the actual log collection happens through the loki.source.docker block. Alloy’s configuration component takes the discovered targets and begins streaming their logs from the discovered containers to Loki. It acts as a bridge, reading lines as they are written and immediately pushing them to the loki.write.local component.


// Scrape logs from Docker containers - send to local
loki.source.docker "docker_logs" {
    host       = "unix:///var/run/docker.sock"
    targets    = discovery.relabel.containers.output
    forward_to = [loki.write.local.receiver]
}

Notice how the targets come from our relabeling output, discovery.relabel.containers. This means every log line will automatically have the labels we configured.

6). Alloy Sends to Local Loki

Let’s tie together how logs actually flow from Alloy to Loki.

We’ve seen how Alloy collects logs from Docker, but the final step is writing them to Loki for storage and querying.

The final destination for logs is Loki and the loki.write component, it points to Loki’s endpoint address. This creates an input point (specifically loki.write.local.receiver) that other components in the configuration can forward their log data to.


loki.write "local" {
    endpoint {
        url = "http://loki:3100/loki/api/v1/push"
    }
}

Grafana Alloy has documentation on using Docker as a Loki Source

Part 2: Alloy Reads - Files (Traefik Access Logs)

Beyond container stdout and stderr logs, we often need to collect structured application logs from files. In this example, we’re using Traefik as a reverse proxy.

Traefik will write access logs in JSON format to a file. This gives us rich information about every HTTP request hitting our infrastructure.

1). Docker - Traefik Mount for Access Logs

In the docker-compose.yml file, there needs to be a section to tell Traefik to export logs to the host so we can read them outside of the container.

You will find "./traefik/access-logs:/opt/access-logs" in your docker-compose.yml file that send our logs to our current directory under traefik and inside of access-logs.


  traefik:
    image: traefik:latest
    container_name: traefik
    volumes:
      - "/var/run/docker.sock:/var/run/docker.sock:ro"
      - "./traefik/access-logs:/opt/access-logs"

2). Traefik Config - Access Logs Type and Location

In your static traefik.yml config, you will need to be sure you’re passing the same path, and telling what kind of log format you need.


################################################################
# Access Logging
################################################################
accessLog:
  filePath: "/opt/access-logs/access.json"
  format: json
  fields:
    defaultMode: keep
    headers:
      defaultMode: keep
      names:
        User-Agent: keep
        Referer: keep
        Forwarded: keep

3). Alloy Docker Volume to Access Traefik Logs in Alloy

This snippet from the docker-compose.yml file creates a target pointing to the access log file.

In the docker-compose.yml, mount the Traefik access logs directory into the Alloy container so it can read these files:


alloy:
  image: grafana/alloy:latest
  volumes:
  - "./traefik/access-logs:/var/log:ro"

4). Access the Access Logs in Alloy

In the config.alloy file, the process of reading file-based logs is slightly different from reading Docker logs.

First, we need to tell Alloy where to find the log files. The local.file_match component generates a target for our file discovery:


local.file_match "traefik_access_logs" {
    path_targets = [{
        __path__ = "/var/log/access.json",
    }]
}

This creates a target, traefik_access_logs, pointing to Traefik’s JSON access log file that we mounted as a volume from our host to our Alloy container.

Grafana Alloy local file documentation

5). Read the File In

Once Alloy knows where the file is, the loki.source.file component can begin tailing it, similar to how the tail -f command works:


loki.source.file "traefik_access" {
    targets    = local.file_match.traefik_access_logs.targets
    forward_to = [loki.process.traefik_labels.receiver]
}

Our new Loki file source, traefik_access, tails the file and forwards new lines to traefik_labels for processing, the next stage in the pipeline - loki.process acts as a middleware layer that modifies the log metadata before storage.

Notice that instead of forwarding directly to Loki, we’re forwarding to that loki.process processing stage first. This is because Traefik’s JSON logs contain structured data that we want to extract into labels for Loki.

Grafana Alloy Loki Source File Documentation

6). Parse JSON and Add Labels

The loki.process block below parses the JSON and creates labels. Traefik writes fields like ClientHost, RequestMethod, and DownstreamStatus in its JSON logs, and we want these as queryable labels in Loki:


// Add labels to Traefik access logs - send raw JSON to Loki
loki.process "traefik_labels" {
    forward_to = [loki.write.local.receiver]

// Drop the filename label (not needed with single file)
stage.label_drop {
    values = ["filename"]
}

// Add a static label so dashboard queries work
    stage.static_labels {
        values = {
            host     = "localhost",
            job      = "traefik",
            log_type = "access",
        }
    }
}

In the block above,

We are forwarding traefik_labels - which was first assigned from our local file match, traefik_access_logs, with output delivered to us from traefik_access, then forwarded onto the loki.process, traefik_labels, above.
stage.label_drop Removes the filename label to reduce index cardinality.
stage.static_labels adds static labels to identify these as Traefik access logs.

You now have file logs and socket logs

One detail to note: the forward configuration, forward_to, appears in multiple places because we have multiple sources.

Both Docker logs and Traefik logs ultimately forward to loki.write.local.receiver.

This receiver has local in it because you can change where logs go by modifying just the loki.write block, and all your sources automatically use the new destination.

Part 3: Sending Logs to Grafana Cloud

You can send your data to the cloud for safe-backup, sure.

But the real reason, is Grafana’s AI integration to the data. It can craft outliers and alerts with a single prompt.

Want to send data to Grafana Cloud? Alloy makes this easy through its forwarding configuration.

In the config.alloy file, you’ll see commented-out blocks for Grafana Cloud. The configuration file was designed so you can enable or disable cloud logging simply by uncommenting those specific lines.

Basic Authentication (User ID + API Key) is also required in the .env file.

If you’ve never used Grafana Cloud, you need an account.

And probably a quick introduction, this video shows how to import local to cloud:

https://youtu.be/Xa3mCIdsno4?t=96

In this setup, you’ll be sending ALL of your logs to the Grafana Cloud. Please be aware, all logs for all containers and all logs being read from all files.

Step 1. Create a Grafana Cloud account

You must have an account to use Grafana Cloud, go ahead and sign up now.

https://grafana.com/auth/sign-up/create-user

Step 2. After account creation - find details here

You need to create and org/Grafana Cloud stack

You can create a token if you go to this page:

[https://.grafana.net/a/grafana-collector-app/alloy/installation](https://.grafana.net/a/grafana-collector-app/alloy/installation)
Once you create a token, you will see an “Install and run Grafana Alloy” section.
This has all of your env_var in place you need. Copy that and go to the .env file. Paste and replace.

Step 3. Add your details assigned to the .env file

You need to enter your username and password for Alloy to be able to export to the cloud.

Again, if using the Grafana Cloud, you will need to uncomment the lines required.

Username and password are stored in an .env file so you never commit those.

// loki.write "grafana_cloud" {
//     endpoint {
//         url = env("GCLOUD_HOSTED_LOGS_URL")
//         basic_auth {
//             username = env("GCLOUD_HOSTED_LOGS_ID")
//             password = env("GCLOUD_RW_API_KEY")
//         }
//     }
// }

Step 4. Uncommenting the cloud endpoint isnt enough!

You must also add the destination for your forward_to lists:

To finish enabling cloud logging, you would uncomment the grafana_cloud block above and then add its receiver to your forwarding configurations.

For example, the Docker logs would be updated from:


forward_to = [
    loki.write.local.receiver,
]

To include both destinations:


forward_to = [
    loki.write.grafana_cloud.receiver,  # Cloud
    loki.write.local.receiver,          # Local
]

This means Alloy sends every log line to multiple destinations simultaneously, this also goes for your Traefik access logs.

Part 4: Sending Grafana Cloud Metrics

Beyond logs, Alloy can also collect and forward metrics. In our configuration, we’re specifically collecting Alloy’s own metrics so we can monitor the health of our logging pipeline itself. This self-monitoring is crucial because if your logging system fails, you need to know about it!

1). Alloy Exporter for Prometheus

The metrics collection starts with the self-monitoring exporter:


prometheus.exporter.self "alloy" { }

This component exposes only Alloy’s internal metrics in Prometheus format.

2). Alloy Prometheus Scraper

Next, we configure a scraper on ourself that periodically collects data metrics from ourself (uncomment to enable):


alloyprometheus.scrape "alloy" {
    targets         = prometheus.exporter.self.alloy.targets
    scrape_interval = "60s"
    forward_to      = [
        // prometheus.remote_write.grafana_cloud.receiver,
        // prometheus.remote_write.local.receiver,
    ]
}

The scrape_interval of sixty seconds means Alloy checks its own metrics every minute.

3). Alloy prom grafana cloud endpoint

In the config.alloy file, you’ll see commented-out blocks for Grafana Cloud prometheus server. The configuration is designed so you can enable or disable cloud logging simply by uncommenting specific lines. Here’s the Grafana Cloud Prometheus endpoint configuration:

You need to enter your username and password.

Username and password are stored in an .env file so you never commit those.


// prometheus.remote_write "grafana_cloud" {
//     endpoint {
//         url = env("GCLOUD_HOSTED_METRICS_URL")
//         basic_auth {
//             username = env("GCLOUD_HOSTED_METRICS_ID")
//             password = env("GCLOUD_RW_API_KEY")
//         }
//     }
// }

Notice the URL is different from the Loki endpoint.

Grafana Cloud separates logs and metrics into different cloud hosted service enpoint urls, each optimized for its data type.

The username here is your hosted metrics ID, which is different from your hosted logs ID.

4). Alloy prom local endpoint

If you’re running your own Prometheus instance locally, you can uncomment and configure the local endpoint:


// prometheus.remote_write "local" {
//     endpoint {
//         url = "http://prometheus:9090/api/v1/write"
//     }
// }

5). Alloy Sends to Local Loki

Now that we’re out of the cloud, let’s tie together - how logs actually flow from Alloy to Loki, one more time.

We’ve seen how Alloy collects logs from Docker and files, but the final step is writing them to Loki for storage and querying.

The final destination for logs is Loki and the loki.write component, it points to Loki’s endpoint address.


loki.write "local" {
    endpoint {
        url = "http://loki:3100/loki/api/v1/push"
    }
}

6). Loki Collection Endpoint - IP or DNS

This is optional choice is configured in the docker-compose file.

You can set the IP address to match to a static IP assigned in the docker-compose.yml, like the config above, let the internal Docker DNS hostname resolution handle it. Make sure you have loki as the container name, or use a static IP


loki:
  image: grafana/loki:latest
  container_name: loki
  ports:
    - "3100:3100"
  networks:
    br1.232:
      ipv4_address: 10.236.232.146

Using a static IP on a Docker network makes the configuration more predictable. You could also use the container name loki instead of the IP.
Port 3100 inside the container to port 3100 on the Docker network.
When Alloy sends logs to Loki, it’s not just sending raw text. Remember all those labels we created during discovery and processing? Alloy bundles those labels with each log line, and Loki indexes them.

Grafana Alloy Loki Write endpoint documentation

Part 5: Loki the endpoind

Loki also goes by the collector, the compressor, the reciever, the accepter, the listener, etc. It has a lot of things it does, but is still very easy to use.

Loki takes logs.

1). How Loki Sets Where It’s Listening

Moving to the Loki side of our stack, we need to configure where Loki accepts incoming logs. This is defined in the loki-config.yaml file under the server section:


server:
  http_listen_port: 3100
  grpc_listen_port: 9096
  http_server_read_timeout: 5s
  http_server_write_timeout: 10s
  log_level: info

The http_listen_port of 3100 is the standard Loki port and matches what we configured in Alloy. Loki actually exposes multiple endpoints on this port. The /loki/api/v1/push endpoint that Alloy uses is for writing logs, while /loki/api/v1/query and /loki/api/v1/query_range are for reading logs (which Grafana uses).
The grpc_listen_port on port 9096 and is used forfor internal gRPC communication, which some clients use instead of HTTP. In our simple setup, we’re not using it, but it’s available if needed.
The http_server_read_timeout limits how long Loki waits to receive the complete request, protecting against slow clients.
The http_server_write_timeout limits how long Loki spends sending a response, preventing queries that take too long from tying up resources.

Loki Server Configuration Documentation

2). Loki Docker Compose Volumes

Loki’s storage configuration determines everything from where log data lives to how it’s organized and accessed.

In this section we’ll look at file storage for loki logs.

Configuring Loki Data on the Host

Loki has to store this data somewhere, if you dump it all in docker volume - I will cry.

Please dont make me cry, please export this data for the host system to have available.

In our docker-compose.yml, we mount a host directory to persist this data, but we need to amke sure to keep permissions correct:


volumes:
  - "./loki/data:/loki"
  - "./loki/config:/etc/loki"

This means all the log data written to /loki inside the container is actually stored in ./loki/data on your host machine. If the Loki container restarts, your logs are safe because they’re outside the container filesystem.

Permissions for Loki Data on the Host

Exporting the data above requires correct permissions.

They must be set for the container, now that these files reside on the host.

The 1_permissions_init_for_project.sh script creates and sets proper permissions for these directories:


LOKI_DATA_DIR="./loki/data"
LOKI_UID=10001
LOKI_GID=10001

mkdir -p "$LOKI_DATA_DIR/rules"
mkdir -p "$LOKI_DATA_DIR/chunks"
mkdir -p "$LOKI_DATA_DIR/wal"

chown -R "$LOKI_UID:$LOKI_GID" "$LOKI_DATA_DIR"

Loki runs as user ID 10001 inside the container, so these directories must be owned by that user ID. The script creates the necessary subdirectories and sets ownership before starting Loki for the first time.

3). Loki Log File Storage Location

In our loki-config.yaml, the storage configuration uses the filesystem mode:


common:
  path_prefix: /loki
  storage:
    filesystem:
      chunks_directory: /loki/chunks
      rules_directory: /loki/rules
  replication_factor: 1

This defines the storage path and tells Loki to store data on the local disk (filesystem) inside /loki/chunks.
The path_prefix sets the base directory for all Loki data. Within this, we have separate directories for different types of data.
The chunks_directory is where actual log data gets written. Loki compresses logs into chunks, which are immutable blocks of data that can be efficiently stored and queried.
replication_factor: 1 is set because you are running a single instance. It won’t try to copy data to other nodes.

4). Loki Log Storage Style

The storage schema configuration tells Loki how to organize this data:


schema_config:
  configs:
    - from: 2024-01-01
      store: tsdb
      object_store: filesystem
      schema: v13
      index:
        prefix: index_
        period: 24h

This configuration is particularly important.

The store: tsdb means Loki uses its Time Series Database index format, which is optimized for time-based queries.
The period: 24h means Loki creates a new index file every twenty-four hours. This makes it efficient to drop old data and keeps index files at manageable sizes.

Lokie Storage Configuration Documentation

5). How Loki Keeps Logs

Back to the config file.

Log retention is a balance between storage costs and regulatory or operational requirements.

The retention configuration starts with the compactor:


compactor:
  working_directory: /loki/compactor
  compaction_interval: 10m
  retention_enabled: true
  retention_delete_delay: 2h
  retention_delete_worker_count: 150
  delete_request_store: filesystem

The compactor runs every ten minutes (controlled by compaction_interval) and performs two key tasks:

It merges small chunks into larger ones for efficiency.
It deletes old data based on retention rules.

Just incase there is a problem the retention_delete_delay of two hours provides a safety buffer.

When the compactor marks data for deletion, it waits two hours before actually removing it, giving you time to recover if you realize you need that data.

6). How Long Loki Keeps Logs

The actual retention period is set in the limits configuration:


limits_config:
  retention_period: 720h  # 30 days
  reject_old_samples: true
  reject_old_samples_max_age: 168h

The retention_period of 720 hours means thirty days.

Any logs older than this will be deleted during compaction.

The reject_old_samples setting prevents clients from writing logs with timestamps older than reject_old_samples_max_age (one week).

This protects against scenarios where a log collector has been offline and tries to push a huge backlog of old logs all at once.

Logs older than 30 days are deleted
Compactor runs every 10 minutes
2-hour safety buffer before actual deletion
Rejects logs older than 7 days at ingestion

Loki Retention Documentation

7). Loki Operational Limits

This provides stability for loki, and ensures that one noisy container (spamming logs) cannot take down the entire logging system.

These limits also control resource usage:


  ingestion_rate_mb: 10
  ingestion_burst_size_mb: 20
  max_query_series: 100000
  max_query_parallelism: 32

The ingestion rate, ingestion_rate_mb: 10, caps the incoming log volume at 10 Megabytes per second. This limits how fast logs can be written, preventing a single container from overwhelming Loki.
The max_query_series stops users from running massive queries (like “show me all logs for all time”) that would crash the server by consuming all resources.
These are reasonable defaults, but you may need to adjust them based on your log volume and query patterns.

8). Loki with GeoIP data

We’re collecting labels from Docker, from Traefik access logs, and potentially from GeoIP lookups. The default Loki limits are quite restrictive, so we’ve increased them to accommodate our rich labeling strategy.


  max_label_names_per_series: 30
  max_label_name_length: 1024
  max_label_value_length: 2048

By increasing max_label_names_per_series to 30, you enable the complex parsing in Alloy. Defaults are often too low for this.
The max_label_... settings are tuned up to allow for rich metadata (like long URLs, complex User-Agents, or GeoIP data) without truncation errors.

Without these increased limits, Loki would reject logs that have too many labels or labels that are too long.

Loki Limits Documentation

Additional Fixes That Might Be Useful

Here are some adustments you can make to your loki-config.yaml, if your setup requires it:

If you have high traffic, you might need to bump ingestion_rate_mb to 50 or 100 to avoid “429 Too Many Requests” errors.
You can add query_timeout: 1m here to automatically kill dashboard queries that hang for too long.

Part 6: Grafana Configuration

Are we there yet? No, so if you have to use the bathroom we can make a quick stop now.

1). How Grafana Looks for Datasources

When Grafana starts, it needs to know where to find its data sources like Loki. Rather than configuring these manually through the UI, we use Grafana’s provisioning system to automatically configure datasources when the container starts.

In our docker-compose.yml, we mount a provisioning directory into Grafana:


volumes:
  - "./grafana/provisioning/:/etc/grafana/provisioning"

Grafana looks for YAML files in specific subdirectories under /etc/grafana/provisioning. The structure follows a convention:

/etc/grafana/provisioning/
  ├── datasources/
  ├── dashboards/
  ├── notifiers/
  ├── alerting/
  └── plugins/

Each subdirectory corresponds to a different type of Grafana configuration. When Grafana starts, it scans these directories and automatically provisions whatever it finds. This is incredibly powerful for infrastructure-as-code approaches because your Grafana configuration lives in version control alongside your application code.

The environment variables in Grafana’s configuration also prepare it for this:


environment:
  - GF_PATHS_PROVISIONING=/etc/grafana/provisioning

This tells Grafana where to look for provisioning files. Although this is the default location, setting it makes the configuration clearer and easier to troubleshoot with docker volume mounts.

Grafana’s provisioning system watches these directories every 10 second and will reload when a file changes, no need to restart the container.

2). How Grafana Finds Loki and Sets the UID

The datasource configuration is where Grafana learns how to connect to Loki. Our configuration lives in ds.yaml:


apiVersion: 1
datasources:
- name: Loki
  type: loki
  uid: lokithedatasourceuid
  access: proxy
  orgId: 1
  url: http://loki:3100
  basicAuth: false
  isDefault: true
  version: 1
  editable: false

Let’s break down each field. The name is what appears in Grafana’s datasource dropdown. The type: loki tells Grafana this is a Loki datasource, which determines what query interface Grafana shows and how it communicates with the backend.

The uid (unique identifier) is particularly important. This identifier is used in dashboard JSON definitions to reference this specific datasource. If you import a dashboard that was built against a Loki datasource with UID lokithedatasourceuid, Grafana will automatically connect the dashboard panels to this datasource. This makes dashboards portable across Grafana instances.

The url points to Loki’s HTTP API at our static IP and port. The access: proxy setting means Grafana acts as a proxy for queries. When you view a dashboard, your browser sends queries to Grafana, and Grafana forwards them to Loki. This is better than direct access because it means Loki doesn’t need to be accessible from users’ browsers, and Grafana can cache and optimize queries.

The isDefault: true setting makes this the default datasource for new panels. When you create a new panel in a dashboard, it automatically selects this Loki instance. The editable: false setting prevents users from modifying this datasource through the UI, which helps maintain consistency in production environments.

This datasource file needs to be placed in the correct location for Grafana to find it. Based on our docker-compose configuration, it should be at:

./grafana/provisioning/datasources/ds.yaml

When Grafana starts, it reads this file and automatically creates the datasource connection to Loki. You’ll see it immediately available in the datasource list without any manual configuration.

3). How Grafana Provisions Dashboards

Dashboards are the visual interface where you query and display your logs. Like datasources, dashboards can be provisioned automatically using configuration files.

The dashboard provisioning configuration is in dashboard.yaml:


apiVersion: 1
providers:
  - name: "default"
    orgId: 1
    folder: ""
    type: file
    disableDeletion: false
    updateIntervalSeconds: 10
    options:
      path: /etc/grafana/provisioning/dashboards

This configuration creates a provider that tells Grafana to look for dashboard JSON files in the specified path. The type: file means dashboards are loaded from files on disk rather than from a database or API.

The updateIntervalSeconds: 10 setting is interesting. Grafana checks this directory every ten seconds for new or modified dashboard files. This means you can drop a new dashboard JSON file into the directory, and within ten seconds, it appears in Grafana without restarting anything.

The disableDeletion: false setting allows dashboards to be deleted through the UI. If this were true, any dashboard from this provider would be read-only and couldn’t be deleted, which is useful in production environments where you want to prevent accidental deletion of important dashboards.

The folder: "" setting means dashboards appear at the root level of Grafana’s dashboard list. You could set this to a folder name like “Production Monitoring” to organize dashboards automatically.

To actually provision dashboards, you would place JSON files in the configured path. Based on our docker-compose volumes, that would be:

./grafana/provisioning/dashboards/

Any JSON file you place there gets loaded as a dashboard. Dashboard JSON files can be exported from Grafana’s UI or created programmatically. They’re large JSON documents that describe every panel, query, and visualization in the dashboard.

Here’s what makes this powerful: you can version control your dashboards alongside your application code. When you deploy a new version of your application, you can deploy updated dashboards at the same time. The dashboards automatically reference our Loki datasource by its UID, so everything connects seamlessly.

4). Adding New Dashboards

You can always search for Grafana Dashboards that other’s have made public. No support provided.

You can edit:

Name: Container Log Dashboard
Folder: Dashboards
Unique identifier (UID): ghNnYnbt

You must edit:

Loki: Select a Loki data source
Import

The Complete Flow

Container logs to Docker → Docker daemon captures them
Alloy discovers containers → Via Docker socket
Alloy applies labels → Container name, stream, etc.
Alloy tails Traefik logs → Parses JSON, adds labels
Alloy sends to Loki → HTTP push to port 3100
Loki indexes and stores → Labels + compressed chunks
Grafana queries Loki → LogQL queries via provisioned datasource
Compactor manages retention → Deletes logs older than 30 days

Part 7: LyrionMediaServer Setup

To demonstrate our monitoring stack in action, we need an application that generates interesting logs. LyrionMediaServer (formerly Logitech Media Server) is a music streaming server that logs every track played, making it perfect for testing our Grafana alerting system.

Persistant Data

We are going to keep persistant data inside of ./appdata/

1). Configure LyrionMediaServer in Docker Compose

The LyrionMediaServer container needs access to your music files and a place to store its configuration. Add this service to your docker-compose.yml:


---
  lyrionmusicserver:
    image: dlandon/lyrionmusicserver
    container_name: LyrionMusicServer
    ports:
      - "9000:9000"    # Web interface
      - "9090:9090"    # CLI interface
      - "3483:3483"    # SlimProto (TCP)
      - "3483:3483/udp" # SlimProto (UDP)
    env_file:
      - .env
    labels:
      - "traefik.enable=true"
      - "traefik.http.services.lyrionmusicserver.loadbalancer.server.port=9000"
      - "traefik.http.routers.lyrionmusicserver.rule=Host(`lms.${DOMAIN}`) || Host(`lyrion.${SUBDOMAIN}`)"
      - "traefik.http.routers.lyrionmusicserver.entrypoints=websecure"
      - "traefik.http.routers.lyrionmusicserver.tls=true"
      - "traefik.http.routers.lyrionmusicserver.tls.certresolver=cloudflare"
      - "traefik.http.routers.lyrionmusicserver.service=lyrionmusicserver"
      - "traefik.http.routers.lyrionmusicserver.tls.domains[0].sans=*.${DOMAIN}"
      - "traefik.http.routers.lyrionmusicserver.tls.domains[1].sans=*.${SUBDOMAIN}"
    volumes:
      - '${MUSIC_STORAGE}:/music:ro'
      - './appdata/lyrion:/config:rw'
    networks:
      br1.232:
        ipv4_address: 10.236.232.138

That was a lot above, what does it all mean:

Port 9000 is the web interface where you manage your music library
Ports 3483 (TCP and UDP) are used by Squeezebox clients to connect to the server
The ipv4_address is set to 10.236.232.138 this is a macvlan address on our host network
The music directory is mounted as read-only (:ro) since the server only needs to read files
Configuration is stored in ./appdata/lyrion on your host for persistence

Access the web interface at http://10.236.232.138:9000 to verify it’s running. The first-time setup wizard will guide you through adding your music library, located at /music.

2). Install the PlayLog Plugin

At time of writing, you will need PlayLog.

This plugin allows you you to log the tracks you listen to, either automatically or by pressing a few remote control buttons. It provides a web interface for viewing its log, linking to the web for more information about what you’ve listened to, and downloading XML and M3U playlists of played songs.

Step 1: Settings > Access Plugin Menu First we need to install PlayLog:

Click on the menu and find the Settings area
Click on Server
On the new page, click the drop down menu at the top
Under plugins in the drop down menu, find Manage Plugins
Click on Manage Plugins in the drop down menu
Use the search field in the upper right corner
playlog should bring up what we need
Check the box for PlayLog
Click Save Settings at the bottom of the page
Restart the LyrionMediaServer container when prompted

Step 2: Configure PlayLog Once the container restarts, go back to Settings > Server:

In the drop down menu, click PlayLog settings (under Plugins section)
Under Current Song Logging, select All tracks (every single track played generates a log entry)
Click Save Settings

Step 5: Enable Debug Logging To get the detailed log format we need for parsing:

Go to Settings → Server Settings → Logging
After clicking on Logging in the drop down menu, you should be on a new page.
Check the box: Save logging settings for use at next application restart
Scroll down to find (plugin.PlayLog) - PlayLog in the list
Change its level from WARN to DEBUG
Click Save Settings

The PlayLog plugin is now configured and will write play events to the Docker logs.

PlayLog Plugin Documentation

3). Connect a Squeezelite Client

LyrionMediaServer needs at least one client connected to actually play music and generate logs. Squeezelite is a lightweight software player that runs on almost any platform.

For Linux/Termux:

If you have a spare Android phone or tablet, you can use Termux (a Linux terminal emulator) and run Squeezelite directly on it.

Once Termux is installed, open it and run:

pkg update
pkg install squeezelite

Start the player:

squeezelite -N my_phone -s 10.236.232.138

The -N my_phone flag sets the player name (this will appear in the LyrionMediaServer web interface)
The -s 10.236.232.138 flag points to your LyrionMediaServer’s IP address
Replace the IP with your actual server address from the docker-compose configuration

For Desktop Clients:

If you prefer a graphical interface, you can download one of these clients:

Squeezelite-X (Windows): Full-featured player with GUI
SqueezePad (iPad): Touch-optimized controller and player
MacOS (MacOS): If you downloaded Lyrion, once installed it will insert a menu into your menu bar right-hand side
Melodeon (Flatpak): Qt5/6 wrapper around MaterialSkin rendered in QWebEngine
Squeezer (Android): I use it to control playback from my Android Wear device
Lyrion (Android): Beautiful execution of a WebView wrapper for accessing a Lyrion Music Server instance using MaterialSkin
Squeezelite (Android): If you dont want to use Termux and would like a GUI

All clients will automatically discover your LyrionMediaServer if they’re on the same network. Note that LyrionMediaServer uses multicast UDP for discovery, so if your clients are on a different network segment, you’ll need to manually specify the server IP address.

4). Add Music and Test Playback

Before we can generate logs, we need music in the library:

Step 1: Add Music Files

Place some MP3s files in your ${MUSIC_STORAGE} directory
Dont have any MP3s? You can always find some new music at OCRemix
Once you have your music in place
In the LyrionMediaServer web interface, go to Settings → Basic Settings
Under Music Folder, click Scan to index your files

Step 2: Start Playing

On your Squeezelite client device, you should see “my_phone” appear in the LyrionMediaServer web interface
Select a song from your library
Press play

Step 3: Verify Logs Are Generated

Watch the Docker logs to confirm PlayLog is working:

docker logs -f LyrionMusicServer

You should see log entries like:

[XX-XX-XX XX:XX:XX.XXXX] Slim::Plugin::PlayLog::Plugin::logTrack (XXX) currently playing "Track Title	file:///.../music.mp3	Artist Name	Album Name"

This log format is what we’ll parse in our Alloy configuration. The fields are tab-separated (\t) in the order: title, file path, artist, album.

Didnt work?

Help is here!

If you don’t see these logs, verify:

PlayLog is set to log “All tracks”
Debug logging is enabled for plugin.PlayLog
The LyrionMediaServer container was restarted after changing logging settings

Part 8: Airsonic Advanced Setup

While LyrionMediaServer gives us basic music playback logs, it’s mainly intended for around the house streaming.

Airsonic Advanced provides a more feature-rich music streaming web-server.

This section demonstrates a different logging pattern: instead of parsing unstructured text logs like we do with LyrionMediaServer, we’ll extract metadata from Airsonic’s file paths and cache operations.

What Is Airsonic Advanced?

Airsonic Advanced is a fork of the Airsonic music server, which itself is a fork of Subsonic. It’s a self-hosted music streaming server with a web interface, mobile apps, and support for transcoding, playlists, and user management.

For our logging stack, Airsonic is interesting because:

It logs every song access through its cache system
We can parse artist and album information from standardized directory structures

A Note About Music Organization

This configuration assumes your music follows a specific directory structure:

/music_folder/Artist/[album-type]/(year) - album_name/track_number - track_title.mp3

For example:

/music/Pink Floyd/[album]/(1973) - The Dark Side of the Moon/01 - Speak to Me.flac
/music/Led Zeppelin/[compilation]/(1990) - Remasters/05 - Whole Lotta Love.mp3

If your music isn’t organized this way, I highly recommend using Beets, a command-line tool that automatically organizes and tags your music library. The Docker image from LinuxServer.io makes this easy:

docker run -v /your/music:/music ghcr.io/linuxserver/beets

Configure Beets with this path format in ~/.config/beets/config.yaml:


paths:
    default: %asciify{$albumartist}/[$albumtype]/($original_year) - $album%aunique{}/$track - $title
    singleton: Non-Album/$artist - $title
    comp: Compilations/%asciify{$albumartist}/($original_year) - $album%aunique{}/$track - $title
    albumtype_soundtrack: Soundtracks/$album/$track $title

This folder structure is the best way to store your complete music archive.

Beets Documentation

1). Configure Airsonic in Docker Compose

Add the Airsonic Advanced service to your docker-compose.yml:


services:
  airsonic-advanced:
    image: airsonicadvanced/airsonic-advanced:latest
    container_name: airsonic-advanced
    environment:
      - TZ=America/Denver
      - CONTEXT_PATH=/
      - JAVA_OPTS=-Xms256m -Xmx512m
    env_file:
      - .env
    ports:
      - "4040:4040"     # WebUI
      - "4041:4041"     # WebUI-HTTPS
      - "1900:1900/udp" # Upnp
    volumes:
      - './appdata/airsonic-advanced:/var/airsonic:rw'
      - '${MUSIC_STORAGE}:/var/music/:ro'
      - '${MUSIC_STORAGE}/_podcasts:/var/podcasts:rw'
      - '${MUSIC_STORAGE}/_playlists:/var/playlists:rw'
    labels:
      - "alloy.job=airsonic"
      - "traefik.enable=true"
      - "traefik.http.services.airsonic.loadbalancer.server.port=4040"
      - "traefik.http.routers.airsonic.rule=Host(`airsonic.${DOMAIN}`) || Host(`music.${SUBDOMAIN}`)"
      - "traefik.http.routers.airsonic.entrypoints=websecure"
      - "traefik.http.routers.airsonic.tls=true"
      - "traefik.http.routers.airsonic.tls.certresolver=cloudflare"
      - "traefik.http.routers.airsonic.tls.domains[0].sans=*.${DOMAIN}"
      - "traefik.http.routers.airsonic.tls.domains[1].sans=*.${SUBDOMAIN}"
    networks:
      br1.232:
        ipv4_address: 10.236.232.156

Configuration details:

Port 4040 is the main web interface
Port 4041 is used for HTTPS if configured
Port 1900 (UDP) is for UPnP/DLNA discovery
The Docker label alloy.job=airsonic is important - we’ll use this to filter logs in Alloy
Configuration persists in ./appdata/airsonic-advanced
Music is mounted read-only; podcasts and playlists are read-write

Access the web interface at http://10.236.232.156:4040. The default credentials are:

Username: admin
Password: admin

Change these immediately after logging in for the first time.

Best Practice: Use Docker Labels for Alloy Discovery

Docker lets you apply labels to containers, and Alloy can use those labels to target the correct container log.

In our example, in docker-compose.yml above:


services:
  airsonic:
    image: ...
    labels:
      - "alloy.job=airsonic"

This adds a Docker label alloy.job with value airsonic to the container.

2). Configure Alloy to Discover Airsonic Container

Now we move to the Alloy side to configure log collection. Unlike our earlier general Docker discovery configuration, we want to create a dedicated pipeline just for Airsonic logs.

In your config.alloy file, we’ll use a two-step approach: first discover all Docker containers, then filter to only the Airsonic container using a relabel rule.

Step 1: Discover Airsonic Using Relabeling

This is our configuration for config.alloy:


// Discover and filter for Airsonic container
discovery.relabel "airsonic_container" {
    targets = discovery.docker.containers.targets

    // Only keep the airsonic-advanced container
    rule {
        source_labels = ["__meta_docker_container_name"]
        regex         = "/airsonic-advanced"
        action        = "keep"
    }

    // Remove the leading slash from container name
    rule {
        source_labels = ["__meta_docker_container_name"]
        regex         = "/(.*)"
        target_label  = "container"
    }

    // Add stream label (stdout/stderr)
    rule {
        source_labels = ["__meta_docker_container_log_stream"]
        target_label  = "stream"
    }
}

This relabeling configuration filters the discovered Docker containers to only include airsonic-advanced. The action = "keep" means any container that doesn’t match the regex is dropped from this pipeline.

The second and third rules clean up the container name (removing the leading / that Docker adds) and add a stream label to distinguish stdout from stderr logs.

Step 1 Alternative: Using Docker Labels Instead of Names

The configuration above filters by container name. If you prefer to use Docker labels (which a way better idea. It’s is more flexible), you can filter by the alloy.job=airsonic label we added in the docker-compose.yml file.

Replace the first rule above with:


rule {
    source_labels = ["__meta_docker_container_label_alloy_job"]
    regex         = "airsonic"
    action        = "keep"
}

Docker labels are converted to Alloy metadata with the pattern: __meta_docker_container_label_<label_name>. Since our label is alloy.job, the dots are converted to underscores, giving us __meta_docker_container_label_alloy_job.

This approach has advantages:

You can apply the same label to multiple containers
You can easily enable/disable monitoring by adding/removing the label
It’s more explicit about which containers are being monitored

4). Configure Alloy to Read Airsonic Logs

With our filtered container targets ready, we can now configure the log source:


// Read logs from Airsonic container
loki.source.docker "airsonic_logs" {
    host       = "unix:///var/run/docker.sock"
    targets    = discovery.relabel.airsonic_container.output
    forward_to = [loki.process.airsonic_enrich.receiver]
}

This loki.source.docker component reads logs from the Docker socket, but only for containers that passed through our relabel filter. Notice we’re not forwarding directly to Loki - instead, logs go to loki.process.airsonic_enrich for enrichment.

This is different from our general Docker log collection because we want to extract additional metadata from Airsonic’s logs before storing them.

5). Parse Airsonic Logs and Add Labels

This is where the magic happens. Airsonic’s cache logs contain file paths, and we can parse the artist name directly from those paths using regex. This creates searchable labels in Loki without storing duplicate data.

Add this processing pipeline to config.alloy:


//================================================================
// AIRSONIC MUSIC LOGS
// Take logs from Airsonic-Advanced into labels
//================================================================

// Filter Docker discovery for airsonic container (by name for now)
discovery.relabel "airsonic_container" {
    targets = discovery.docker.containers.targets

    // Only keep a containers with label: "alloy.job=airsonic"
    rule {
        source_labels = ["__meta_docker_container_label_alloy_job"]
        regex         = "airsonic"
        action        = "keep"
    }

    rule {
        source_labels = ["__meta_docker_container_log_stream"]
        target_label  = "stream"
    }
}

// Scrape ONLY airsonic logs from Docker
loki.source.docker "airsonic_logs" {
    host       = "unix:///var/run/docker.sock"
    targets    = discovery.relabel.airsonic_container.output
    forward_to = [loki.process.airsonic_enrich.receiver]
}

// Parse and enrich airsonic logs with IP, username, and artist info
loki.process "airsonic_enrich" {
    forward_to = [loki.write.local.receiver]

        // Add static job label FIRST (always applied)
        stage.static_labels {
            values = {
                job = "airsonic",
            }
        }

        // Extract IP from StreamController logs
        stage.match {
            selector = "{job=\"airsonic\"} |~ \"StreamController.*listening to\""

            stage.regex {
                expression = "(?P<ip>\\d+\\.\\d+\\.\\d+\\.\\d+): (?P<username>\\w+) listening to"
            }

            stage.labels {
                values = {
                    asonic_ip = "ip",
                    asonic_user  = "username",
                    log_type  = "stream",
                }
            }
        }

        // Extract artist from CacheConfiguration logs
        stage.match {
            selector = "{job=\"airsonic\"} |~ \"Cache Key:.*\\\\[(?:album|compilation|remix|single|ep)\\\\]\""

            stage.regex {
                expression = "Cache Key: (?P<artist>[^/]+)/\\[(?:album|compilation|remix|single|ep)\\]/"
            }

            stage.labels {
                values = {
                    asonic_music   = "artist",
                    log_type = "cache",
                }
            }
        }
}

Let’s break down what each stage does:

Stage 1: Static Labels

The stage.static_labels block adds job="airsonic" to every log line that enters this pipeline. This happens first, before any matching or parsing.

Stage 2: Stream Log Parsing

The first stage.match block looks for logs containing StreamController and listening to. These are generated when a user starts playing a track. An example log looks like:

192.168.1.100: johndoe listening to /var/music/Pink Floyd/[album]/(1973) - Dark Side/01 - Speak to Me.flac

The stage.regex extracts:

ip - The client’s IP address (192.168.1.100)
username - The Airsonic username (johndoe)

The stage.labels block converts these into Loki labels:

asonic_ip="192.168.1.100"
asonic_user="johndoe"
log_type="stream"

Stage 3: Cache Log Parsing

The second stage.match block processes cache access logs. These are generated when Airsonic reads file metadata.

An example log:

Cache Key: Pink Floyd/[album]/(1973) - Dark Side of the Moon/01 - Speak to Me.flac

The regex extracts the artist name (Pink Floyd) from the file path. The [^/]+ pattern means “capture everything up to the first forward slash”, which corresponds to our artist folder.

The regex also validates the album type is one of: album, compilation, remix, single, or ep. This prevents false matches on other file paths.

The extracted data becomes:

asonic_music="Pink Floyd"
log_type="cache"

Logs that don’t match either stage selector still get the job="airsonic" label but skip the extraction stages. This includes error logs, startup messages, and other operational logs.

6). Understanding the Label Hierarchy

After processing, your logs will have different labels depending on their type. Here’s the complete label hierarchy:

All Airsonic Logs:

job="airsonic" - Always present
container="airsonic-advanced" - From discovery

Stream Logs (user playback):

All labels from “All Airsonic Logs”
asonic_ip - Client IP address
asonic_user - Username
asonic_music - Artist name

This labeling strategy lets you write precise queries in Grafana:

{job="airsonic"} - All Airsonic logs
{job="airsonic", log_type="stream"} - Only playback events
{job="airsonic", asonic_music="Pink Floyd"} - Only Pink Floyd songs accessed
{job="airsonic", asonic_user="admin"} - Only admin’s activity

7). Verify Airsonic Log Collection

After adding this configuration to Alloy and restarting the container, verify it’s working:

Step 1: Check Alloy UI

Navigate to http://your-alloy-host:12345/component/loki.process.airsonic_enrich

You should see:

Metrics showing logs processed
The pipeline stages listed
Any errors if the regex isn’t matching

Step 2: Play a Song in Airsonic

Go to your Airsonic web interface and play a song.

Step 3: Query in Grafana

Open Grafana and go to Explore. Select your Loki datasource and run:

{job="airsonic"} | asonic_music != ""

You should see logs with the asonic_music label populated with artist names. If the label is empty or missing, check:

Your music folder structure matches the expected format
The regex in the stage.regex block matches your actual log format
The cache logs are actually being generated (they may take a moment after playback starts)

Part 9: Grafana Alerting System

Now that we have music streaming logs flowing into Loki with rich labels, we can configure Grafana’s alerting system to notify us when specific songs or artists are played. This demonstrates the complete monitoring pipeline: logs → parsing → storage → alerting → notification.

Grafana’s alerting system consists of three components that work together:

Alert Rules - Define what conditions trigger an alert
Contact Points - Define where to send notifications
Notification Policies - Define routing and timing behavior

We’ll configure all three to send Telegram notifications when certain music is played.

How Grafana Alerting Works

Before diving into configuration, it helps to understand the alert flow:

Step 1: Evaluation

Grafana periodically runs LogQL queries defined in alert rules. These queries check your Loki data for specific conditions.

Step 2: State Change

When a query result crosses a threshold, the alert state changes from “Normal” to “Alerting”. This state change is what triggers the next steps.

Step 3: Notification Policy Matching

The alert is evaluated against notification policies. These policies determine which contact point receives the alert and control timing behaviors like grouping and repeat intervals.

Step 4: Contact Point Execution

The selected contact point sends the notification to its configured destination (Telegram, email, Slack, etc.).

Step 5: Repeat and Resolution

If the alert condition persists, notifications repeat according to the policy. When the condition clears, a resolution notification can optionally be sent.

1). Configure Telegram Bot for Notifications

Before we can send alerts to Telegram, we need to create a bot and get its credentials. This is a one-time setup process.

Step 1: Create a Telegram Bot

Open Telegram and search for @BotFather
Send the command /newbot
Follow the prompts to choose a name and username for your bot
BotFather will respond with a token like 112233445:AAQQqTtvv11gGHJXxfFtESEOsaAcKsSBlaDWin
Save this token - you’ll need it for the Grafana configuration

Step 2: Get Your Chat ID

Search for @userinfobot in Telegram
Send it any message
It will reply with your user ID (a number like 123456789)
This is your chat ID for personal messages

Step 3: If you want to send alerts to a group

Create a group and add your bot to it
Add @userinfobot to the group temporarily
The bot will show the group’s chat ID (it will be negative, like -987654321)
Remove @userinfobot after getting the ID

Step 4: Add Credentials to .env File

Add these lines to your .env file:


MYTGRAM_BOTTOKEN=112233445:AAQQqTtvv11gGHJXxfFtESEOsaAcKsSBlaDWin
MYTGRAM_CHATID=123456789

Replace the values with your actual bot token and chat ID. These environment variables keep your credentials out of the configuration files.

2). Create Telegram Contact Point

Contact points define where Grafana sends notifications. We’ll create one for Telegram using the provisioning system so it’s automatically configured when Grafana starts.

We will be using the file ./grafana/provisioning/alerting/ContactPoint-Telegram.yaml:


apiVersion: 1
contactPoints:
  - orgId: 1
    name: MusicAlert_bot
    receivers:
      - uid: telegram_music_alerts
        type: telegram
        settings:
          bottoken: ${MYTGRAM_BOTTOKEN}
          chatid: >
            ${MYTGRAM_CHATID}
          disable_notification: false
          disable_web_page_preview: false
          protect_content: false
        disableResolveMessage: true

Let’s break down this configuration:

Contact Point Identification

name: MusicAlert_bot - This is how you reference this contact point in notification policies
uid: telegram_music_alerts - A unique identifier for this specific receiver

Telegram Settings

bottoken - References your bot token from the .env file
chatid - Your personal or group chat ID (see the note below about the > syntax)
disable_notification: false - Messages will trigger sound/vibration on your phone
disable_web_page_preview: false - Telegram will show previews for any URLs in messages
protect_content: false - Allows forwarding and saving messages

Alert Behavior

disableResolveMessage: true - When an alert clears, Grafana won’t send a “resolved” notification. This prevents notification spam when music stops playing.

Important: The ChatID YAML Syntax

You’ll notice the chatid uses special YAML syntax:


chatid: >
  ${MYTGRAM_CHATID}

The > symbol is a YAML folded scalar. This is necessary because of a bug in Grafana’s YAML parser (issue #69950). The chat ID is a number, but Telegram’s API requires it as a string. Without the folded scalar syntax, Grafana interprets the environment variable as a number and the API call fails.

The indentation matters - the ${MYTGRAM_CHATID} line must be indented relative to chatid:. This forces YAML to treat the entire value as a string type, even though it contains only digits.

This is not the only solution, but it’s the cleanest way to handle numeric values that need to be strings without hardcoding quotes (which would prevent environment variable expansion).

Grafana Telegram Configuration Documentation

3). Create Notification Policy

Notification policies control the routing and timing of alerts. They determine which contact point receives each alert and how often notifications repeat.

We will be using the file ./grafana/provisioning/alerting/Notification-Policy.yaml:


apiVersion: 1
policies:
  - orgId: 1
    receiver: MusicAlert_bot
    group_by:
      - grafana_folder
      - alertname
    group_wait: 0s
    group_interval: 5m
    repeat_interval: 10m

Routing Configuration

receiver: MusicAlert_bot - All alerts matching this policy go to our Telegram contact point
This is the root policy, so it applies to all alerts by default

Grouping Configuration

group_by: [grafana_folder, alertname] - Alerts are grouped by their folder location and rule name
This means if both the Airsonic and Lyrion alerts fire simultaneously, they’ll be sent as separate notifications
Without grouping, you’d get one notification per label combination, which could be dozens of messages

Timing Configuration

group_wait: 0s - Send notifications immediately, don’t wait to collect more alerts into the group
group_interval: 5m - If more alerts join this group, wait 5 minutes before sending an update
repeat_interval: 10m - If the alert condition persists, resend the notification every 10 minutes

This timing configuration is tuned for music alerts where:

You want immediate notification when someone starts playing monitored songs
You don’t want spam if they listen to multiple songs in a row (hence the 5-minute grouping)
You want periodic reminders if they’re binge-listening (every 10 minutes)

Extending This Policy

You can add nested policies for more complex routing. For example, to send critical alerts to Telegram with sound and warning alerts via email:


policies:
  - orgId: 1
    receiver: MusicAlert_bot
    routes:
      - receiver: MusicAlert_bot
        matchers:
          - severity = critical
        group_wait: 0s
      - receiver: email_team
        matchers:
          - severity = warning
        group_wait: 5m

You can also add mute timings to silence notifications during specific hours:


mute_time_intervals:
  - name: sleep_hours
    time_intervals:
      - times:
        - start_time: '23:00'
          end_time: '08:00'

Then reference it in your policy:


policies:
  - orgId: 1
    receiver: MusicAlert_bot
    mute_time_intervals:
      - sleep_hours

Grafana Notification Policy Documentation

4). Create Alert Rule for Lyrion Music

Alert rules define the actual conditions that trigger notifications. We’ll create two rules: one for LyrionMediaServer and one for Airsonic. These demonstrate different approaches to log parsing.

The LyrionMediaServer alert uses regex to parse unstructured text logs at query time. We will be using the file ./grafana/provisioning/alerting/LyrionAlert.json:

  "apiVersion": 1,
  "groups": [
    {
      "orgId": 1,
      "name": "10s",
      "folder": "alerts",
      "interval": "10s",
      "rules": [
        {
          "uid": "cf74nwa8akxdsc",
          "title": "Lyrion Playing Favorite Music",
          "condition": "C",
          "data": [
            {
              "refId": "A",
              "queryType": "range",
              "relativeTimeRange": {
                "from": 30,
                "to": 0
              },
              "datasourceUid": "lokithedatasourceuid",
              "model": {
                "editorMode": "code",
                "expr": "sum by (title, artist) (\n  rate({container=~\"(?i)(lyrionmusicserver|lms)\"} \n    |= \"currently playing\" \n    |~ `(?i)(nickelback|creed|insane clown posse|limp bizkit|crazy potato)`\n    | regexp `currently playing \"(?P<title>[^\\t]+)\\t(?P<url>[^\\t]+)\\t(?P<artist>[^\\t]+)\\t`\n  [3s])\n)",
                "instant": true,
                "intervalMs": 1000,
                "legendFormat": "",
                "maxDataPoints": 43200,
                "queryType": "range",
                "refId": "A"
              }
            },
            {
              "refId": "reducer",
              "queryType": "expression",
              "relativeTimeRange": {
                "from": 0,
                "to": 0
              },
              "datasourceUid": "__expr__",
              "model": {
                "conditions": [
                  {
                    "evaluator": {
                      "params": [
                        0,
                        0
                      ],
                      "type": "gt"
                    },
                    "operator": {
                      "type": "and"
                    },
                    "query": {
                      "params": []
                    },
                    "reducer": {
                      "params": [],
                      "type": "avg"
                    },
                    "type": "query"
                  }
                ],
                "datasource": {
                  "name": "Expression",
                  "type": "__expr__",
                  "uid": "__expr__"
                },
                "expression": "A",
                "intervalMs": 1000,
                "maxDataPoints": 43200,
                "reducer": "last",
                "refId": "reducer",
                "type": "reduce"
              }
            },
            {
              "refId": "C",
              "relativeTimeRange": {
                "from": 0,
                "to": 0
              },
              "datasourceUid": "__expr__",
              "model": {
                "conditions": [
                  {
                    "evaluator": {
                      "params": [
                        0
                      ],
                      "type": "gt"
                    },
                    "operator": {
                      "type": "and"
                    },
                    "query": {
                      "params": [
                        "C"
                      ]
                    },
                    "reducer": {
                      "params": [],
                      "type": "last"
                    },
                    "type": "query"
                  }
                ],
                "datasource": {
                  "type": "__expr__",
                  "uid": "__expr__"
                },
                "expression": "reducer",
                "intervalMs": 1000,
                "maxDataPoints": 43200,
                "refId": "C",
                "type": "threshold"
              }
            }
          ],
          "noDataState": "OK",
          "execErrState": "Error",
          "isPaused": false,
          "notification_settings": {
            "receiver": "MusicAlert_bot"
          }
        }
      ]
    }
  ]
}

Understanding the LogQL Query Above


sum by (title, artist) (
  rate({container=~"(?i)(lyrionmusicserver|lms)"}
    |= "currently playing"
    |~ `(?i)(nickelback|creed|insane clown posse|limp bizkit|crazy potato)`
    | regexp `currently playing "(?P<title>[^\t]+)\t(?P<url>[^\t]+)\t(?P<artist>[^\t]+)\t`
  [3s])
)

Let’s break this down line by line:

Line 1: Label Filter

{container=~"(?i)(lyrionmusicserver|lms)"} - Select logs from containers named “lyrionmusicserver” or “lms”
The (?i) makes the match case-insensitive
The =~ operator means “matches this regex”

Line 2: Line Filter

|= "currently playing" - Only logs containing this exact phrase
This is a fast filter that runs before regex parsing
Line filters are much faster than regex, so always use them when possible

Line 3: Content Filter

|~ (regex pattern) - Only logs matching this regex pattern
Looks for song titles or artists containing our monitored bands
The list includes: Nickelback, Creed, Insane Clown Posse, Limp Bizkit, Crazy Potato

Line 4: Parse and Extract

| regexp - Parse the log line and extract named groups
(?P<title>[^\t]+) - Capture the song title (everything up to the first tab)
(?P<artist>[^\t]+) - Capture the artist name (after the second tab)
These become labels we can use in aggregations

Line 5: Rate Calculation

[3s] - Calculate the rate over a 3-second window
This converts log line counts into events per second

5). Create Alert Rule for Airsonic Music

The Airsonic alert uses pre-parsed labels from our Alloy configuration, making the query much simpler and more efficient.

We will be using the file ./grafana/provisioning/alerting/AirsonicAlert.json:


{
  "apiVersion": 1,
  "groups": [
    {
      "orgId": 1,
      "name": "10s",
      "folder": "alerts",
      "interval": "10s",
      "rules": [
        {
          "uid": "cf7i3a4c54d1ce",
          "title": "Lyrion Playing Favorite Music",
          "condition": "C",
          "data": [
            {
              "refId": "A",
              "queryType": "instant",
              "relativeTimeRange": {
                "from": 600,
                "to": 0
              },
              "datasourceUid": "lokithedatasourceuid",
              "model": {
                "editorMode": "code",
                "expr": "sum by (asonic_music) (\n  rate({job=\"airsonic\"} \n    | asonic_music =~ `(?i)(nickelback|creed|fred durst|Rick Astley|Limp Bizkit)`\n  [3m])\n)",
                "instant": true,
                "intervalMs": 1000,
                "maxDataPoints": 43200,
                "queryType": "instant",
                "refId": "A"
              }
            },
            {
              "refId": "C",
              "relativeTimeRange": {
                "from": 0,
                "to": 0
              },
              "datasourceUid": "__expr__",
              "model": {
                "conditions": [
                  {
                    "evaluator": {
                      "params": [
                        0
                      ],
                      "type": "gt"
                    },
                    "operator": {
                      "type": "and"
                    },
                    "query": {
                      "params": [
                        "C"
                      ]
                    },
                    "reducer": {
                      "params": [],
                      "type": "last"
                    },
                    "type": "query"
                  }
                ],
                "datasource": {
                  "type": "__expr__",
                  "uid": "__expr__"
                },
                "expression": "A",
                "intervalMs": 1000,
                "maxDataPoints": 43200,
                "refId": "C",
                "type": "threshold"
              }
            }
          ],
          "noDataState": "OK",
          "execErrState": "Error",
          "isPaused": false,
          "notification_settings": {
            "receiver": "MusicAlert_bot"
          }
        }
      ]
    }
  ]
}

Understanding the LogQL Query

This query is much simpler than the Lyrion one because:


sum by (asonic_music) (
  rate({job="airsonic"}
    | asonic_music =~ `(?i)(nickelback|creed|fred durst|Rick Astley|Limp Bizkit)`
  [3m])
)

Line 1: Label Filter

{job="airsonic"} - Select only Airsonic logs
This is a label we added in our Alloy stage.static_labels block

Line 2: Label Matcher

| asonic_music =~ (regex) - Filter on the pre-parsed artist label
This label was extracted by our Alloy stage.regex from the cache file paths
No regex parsing needed at query time - the work was already done by Alloy

Line 3: Rate and Aggregation

[3m] - Calculate rate over a 3-minute window (longer than Lyrion because Airsonic logs are less frequent)
sum by (asonic_music) - Group by artist name

Why This Is More Efficient

The Lyrion query must:

Search log content for keywords
Parse each matching log with regex
Extract title and artist at query time
Then aggregate the results

The Airsonic query:

Filter by job label (indexed, very fast)
Filter by artist label (also indexed)
Aggregate

By doing the parsing in Alloy, we’ve moved the expensive work from query time (when you’re viewing dashboards) to ingestion time (when logs arrive). This makes dashboards faster and reduces load on Loki.

The tradeoff is that you need to know what you want to extract before logs arrive. You can’t retroactively add labels to old logs. The Lyrion approach is more flexible - you can change the regex in your query anytime - but it’s slower.

6). Test the Alert System

Now for the fun part - testing if everything works:

Step 1: Verify Contact Point

In Grafana, go to Alerting → Contact points
Find “MusicAlert_bot” in the list
Click Test to send a test message to your Telegram
You should receive a test notification within a few seconds

If the test fails:

Check your bot token is correct in the .env file
Verify you’ve started a conversation with your bot in Telegram (send it any message first)
For group chats, ensure the bot was added before you got the chat ID

Step 2: Play a Monitored Song

Open either LyrionMediaServer or Airsonic
Play a song by one of the monitored artists (Nickelback, Creed, etc.)
Wait up to 30 seconds for the alert to evaluate
Check your Telegram for a notification

The notification should include:

The alert title
A summary showing which artist/song triggered it
A timestamp
Links back to Grafana

Step 3: Verify Alert State in Grafana

Go to Alerting → Alert rules
The triggered alert should show state “Alerting” with a red background
Click on the alert to see its evaluation history and labels

If the alert doesn’t fire:

Check the query returns data in Explore (use the same LogQL query from the alert)
Verify your logs are being collected (check {job="airsonic"} or {container=~"lyrion.*"})
Look at Grafana’s logs for evaluation errors: docker logs grafana

7). Customizing Alert Behavior

Now that the basic system works, here are some ways to customize it:

Add More Artists: Simply edit the regex pattern in the JSON files. For example, to also monitor for Taylor Swift:

|~ `(?i)(nickelback|creed|taylor swift|fred durst)`

Alert on Specific Users: Modify the Airsonic query to include the user label:


sum by (asonic_music, asonic_user) (
  rate({job="airsonic", asonic_user="johndoe"}
    | asonic_music =~ `(?i)(nickelback|creed)`
  [3m])
)

Change Notification Frequency: Edit Notification-Policy.yaml:

Reduce repeat_interval to 5m for more frequent reminders
Increase group_interval to 10m to batch more alerts together

Add Severity Levels: Create separate alerts with different severity labels, then route them to different contact points:


routes:
  - receiver: telegram_urgent
    matchers:
      - severity = critical
  - receiver: email_team
    matchers:
      - severity = warning

Mute During Sleep Hours: Add mute timings to the notification policy:


mute_time_intervals:
  - name: night_hours
    time_intervals:
      - times:
        - start_time: '22:00'
          end_time: '07:00'
        weekdays: ['saturday', 'sunday']

The Complete Monitoring Flow

Let’s trace a single log line through the entire system to see how all the pieces connect:

Step 1: Music Plays A user plays “Photograph” by Nickelback in Airsonic.

Step 2: Airsonic Logs Airsonic writes a cache access log to stdout:

Cache Key: Nickelback/[album]/(2005) - All The Right Reasons/01 - Photograph.flac

Step 3: Docker Captures The Docker daemon captures this stdout log from the container.

Step 4: Alloy Discovers The discovery.docker block finds the Airsonic container.

Step 5: Alloy Filters The discovery.relabel block matches the container name and keeps it for processing.

Step 6: Alloy Reads The loki.source.docker block reads the log line from Docker.

Step 7: Alloy Parses The loki.process pipeline:

Adds label: job="airsonic"
Matches the cache pattern
Extracts: asonic_music="Nickelback"
Adds label: log_type="cache"

Step 8: Alloy Sends The processed log with all labels is sent to Loki at port 3100.

Step 9: Loki Stores Loki indexes the labels and compresses the log line for storage.

Step 10: Grafana Queries Every 30 seconds, Grafana runs the alert query:


{job="airsonic"} | asonic_music =~ `(?i)(nickelback|...)`

Step 11: Condition Triggers The query returns a rate > 0, so the condition evaluates to true.

Step 12: Policy Routes The notification policy matches the alert and selects the “MusicAlert_bot” contact point.

Step 13: Telegram Sends The contact point uses the Telegram API to send a message to your phone.

Step 14: You React Your phone buzzes with: “Airsonic playback detected: Nickelback”

And that’s the complete flow from music playback to mobile notification, demonstrating the power of modern observability stacks for both serious monitoring and fun use cases like this.

Grafana Alerting Overview LogQL Query Language Documentation Telegram Bot API Documentation

YAML tirade

To get a string working in YAML, it’s a little tricky. chatid is required to be a string, but it is a number. So just passing an env_var in, isnt correct.

The Solution

Use YAML multiline syntax to force this as a string:


yamlapiVersion: 1
contactPoints:
    - orgId: 1
      name: MusicAlert_bot
      receivers:
        - uid: nj9087ns47
          type: telegram
          settings:
            bottoken: ${MYTGRAM_BOTTOKEN}
            chatid: >
              ${MYTGRAM_CHATID}
            disable_notification: false
            disable_web_page_preview: false
            protect_content: false
          disableResolveMessage: true

What the Scalar Solution Does

Why this works:

The Indentation: By indenting ${MYTGRAM_CHATID}, the YAML parser treats it as the value of chatid.
The Folded Scalar (>): The > symbol tells YAML: “Everything indented below this is a string.”
No Quotes: Since you aren’t using literal “ or ‘ marks, Grafana receives the raw digits but treats them as a string type.

This forces Grafana to treat it as a string instead of a number.

Why This Bug Exists

Grafana’s YAML parser expands environment variables before type checking, so numbers - even with quotes around them - get parsed as numeric types instead of strings. This is a known bug (#69950) that’s been open since June 2023.

Grafana, Alloy, Loki using Docker alerting on our favorite song
