Gitlab Up and Running on Docker with Runners and TLS in the Homelab

GitLab Omnibus is a massive “all-in-one” platform that bundles databases, web servers, and task runners into a single package.

Getting your own self-hosted DevSecOps platform running doesn’t have to be a headache.

This guide will get you a professional-grade GitLab CE instance, secured with TLS (HTTPS) via Traefik, a pre-configured GitLab Runner, and a CI/CD pipeline project, in under 15 minutes.

To find the repository that goes along with this guide, visit:

github.com/MarcusHoltz/docker-gitlab-runner

The Architecture at a Glance

Before we dive in, here is how the traffic flows through this stack:

Traefik: Acts as the traffic cop, handling SSL termination and routing.
Certbot: Automatically fetches Wildcard certificates via Cloudflare DNS.
GitLab CE: The core application, running on an internal Docker network.
GitLab Runner: Automatically registers itself to your instance using a helper script.
WeatherCICD: This is the gitlab-ci.yml pipeline that we will run once the project is complete.

1). Configure the Project Environment to Your Requirements

You need to tell the stack a few details.

./certbot/cloudflare.ini - This file tells Certbot your Cloudflare API Token for DNS-01
./secrets/gitlab_root_password.txt - This file contains our intial password to login to GitLab as root
.env - The .env file is where we place every other non-secret value. It contains all the customization within our script.

Edit ./certbot/cloudflare.ini

The first step is to leave this write-up and go to another website.

Cloudflare can provide a nameserver for almost any domain, allowing us to use Cloudflare’s API to create temporary TXT records for SSL domain validation.

For help with creating a Token in Cloudflare, visit Cloudflare’s docs on creating a token for a quick how-to.

Once you have the token,

Go inside the cerbot folder
Edit the cloudflare.ini file
Find dns_cloudflare_api_token
Replace YOUR_CLOUDFLARE_API_TOKEN_HERE with your token
Save and quit the file

Ensure the token has “Zone:DNS:Edit” permissions for your domain.

Edit ./secrets/gitlab_root_password.txt

To keep passwords secure, we will use Docker Secrets.

Go inside the folder named secrets
Edit a file inside called gitlab_root_password.txt
You should see a placeholder password, HEYOUchangeThisPassword
Remove that text and enter your password (your password should be the only text in the file)
Save and quit the file

Make sure to paste just your GitLab root password

Edit .env

The .env file is were we store everything we want to configure in all of our files (outside of our secrets).

This allows us to make changes in one place throughout the entire project, but keep our keys, tokens, passwords, and secrets safe somewhere else.

Open your .env file
You must atleast update the following fields:
- DOMAIN_NAME: Your domain (e.g., example.com).
- GITLAB_SUBDOMAIN: Usually gitlab.
- GITLAB_HOST_IP: The IP address of your Docker host running GitLab
There are many more fields, change a few more and you may just break something - Good Luck!

2). Spin Up the Stack

With configuration complete, you can bring up the Docker compose project stack.

docker compose up -d

What’s happening?

Certbot runs first to ensure your SSL certificates exist in ./appdata/certbot.
Traefik starts listening on ports 80 and 443, but will need rebooted to find the certificates.
GitLab begins its boot sequence.

What can I do?

I would say, to let everything get everything settled, run this command and walk away:

docker compose up -d && sleep 180 && docker compose up -d && sleep 270 && docker logs -f gitlab_ce

GitLab is heavy. It can take 5–10 minutes to fully initialize. You can monitor the progress with docker logs -f gitlab_ce.

Problems?

See the Help section at the end.

3.) Runner Registration Script

Usually, registering a runner is a manual chore of copying tokens. I have automated this with the register_gitlab_runner.sh script.

Once GitLab is healthy (you can reach the login page), run:

register_gitlab_runner.sh

What the register_gitlab_runner.sh script does for you

Wait: It polls the GitLab API until it’s actually ready.
Auth: It enters the GitLab container and generates a temporary Personal Access Token.
Register: It fetches a Runner Registration Token and links the gitlab-runner container to your instance.
Connect: It configures the runner to use the Docker executor, allowing it to run CI/CD jobs.

Navigate to https://gitlab.yourdomain.com.
Log in with username root and the password you put in your secrets file.
Go to Admin Area > CI/CD > Runners. You should see your homelab-hybrid-runner online and ready!

4). Your First Project

With your recent sucess of logging into GitLab, we should do something with it.

I have provided a gitlab-ci pipeline to do exactly that!

Login to GitLab, if not already
In the upper right hand corner of the screen is a + icon, click it
In this new GitLab menu, click New project/repository
On the new screen click on Create blank project
Enter a project name
Under the Project URL use the drop down for Pick a group or namespace to select an option (probably just root)
Under Project Configuration uncheck - Initialize repository with a README
Click on Create project
On this new screen, with your newly minted repo, head down to the Add files
Click on HTTPS
We want to Configure the Git repository for our WeatherCICD folder, copy and paste these commands somewhere

Git Push the WeatherCICD

With a new reposity to hold our files, we can put the WeatherCICD into GitLab.

Open the folder in the docker-gitlab-runner repository under WeatherCICD.
Once inside the WeatherCICD folder
Here you can use the commands we copied from your new repository
They should look like


git init --initial-branch=main --object-format=sha1
git remote add origin https://<your-domain>/<user>/<repo>.git
git add .
git commit -m "Initial commit"
git push --set-upstream origin main

Once you git pushed - you should see your new files in GitLab.

5). Weather CI/CD Demo

This project demonstrates GitLab CI/CD pipelines with interactive user input.

Getting Weather CI/CD Demo Running

Set up your API key:
- Get a free API key from OpenWeatherMap
- Add it in Settings → CI/CD → Variables
- Click Add variable
- Enter the Key as WEATHER_API_KEY
- Enter the Value with the free API key you got from OpenWeatherMap
- Save changes
Run your first pipeline:
- Go to Build → Pipelines
- Click New Pipeline
- Fill out the form with your desired location
- Click New Pipeline
Watch the magic happen:
- See real-time logs
- Watch as nothing happens
- The ‘main’ branch has manual builds
- To fix: Make a new branch below
- Or click: The stuck job card or run (play) button in your current pipeline
Make a new Branch:
- To push a new README.md automatically to the repository
- You need to make a new branch not named, ‘main’ or ‘webdav’
- Go to Code → Branches
- Click New Branch
- Fill out the form with your desired branch name (be sure to ‘create from’ main)
- Click Create Branch
Run a pipeline in a branch:
- Go to Build → Pipelines
- Click New Pipeline
- Look in the upper left hand corner of this form
- Run for branch name or tag
- Select the branch you made
- Fill out the form with your desired location
- Click New Pipeline
Watch your README.md change:
- See real-time logs
- Visit your README.md for the changes

Help

1. Ok, now run the compose file

Deploy the stack using docker compose up -d.

The Novice Trap: The “502 Bad Gateway” Panic Immediately after running this, you will likely see a 502 error in your browser. Don’t panic. GitLab is an “Omnibus” package containing a database, a registry, and a web server; it takes 5–10 minutes to run its internal configuration scripts. If you restart the container during this phase, you risk corrupting the database.

Understanding Your Config:

External URL: Your external_url in the config must start with https://. Even though Traefik handles the encryption, GitLab needs to know it is being served via HTTPS to generate the correct internal links.
Port 80 vs 443: You’ll see nginx['listen_https'] = false. This is intentional. Traefik catches the secure traffic on port 443 and passes it to GitLab’s internal port 80. If you enable HTTPS inside GitLab too, you’ll get a port conflict and the deployment will fail.
Port 22 Conflict: If your host machine already uses port 22 for SSH (it usually does), your GitLab SSH will fail. Check if your config maps port 22 to a different host port (like 2424:22) to avoid this.

2. Super, now run the runner setup script

Now that the instance is alive, run your setup script to connect the “worker” (the Runner).

The Novice Trap: The “410 Gone” Error As of 2025, GitLab has deprecated “Registration Tokens.” If you try to use a static token from an old tutorial, you will get a 410 Gone error.

The Fix: You must create the Runner in the UI first (Admin > CI/CD > Runners) to get an Authentication Token (prefixed with glrt-).

What the script does for you:

Docker Executor: It sets the executor to docker. This ensures every build job runs in a clean, isolated container.
The Socket Mount: It mounts /var/run/docker.sock. This is high-value because it lets your runner spin up other containers, but it means the runner has root-level power over your server. Keep this instance private!

You need your password, and it wasn’t set in the compose file.

Retrieve your temporary key: GitLab generates a random password on boot. Run this command to see it: docker exec -it gitlab grep 'Password:' /etc/gitlab/initial_root_password.

4. Cool, create your first repo

Click “New Project” > “Create blank project.”

Novice Tip: If you’re using this for internal tools, set the visibility to Private.
Novice Tip: Don’t skip the “Initialize with a README” checkbox; it makes the next step easier to verify.

5. Now connect the gitlab-ci repo

Connect your local code to your new instance using these commands on your screen:

git remote add origin https://<your-domain>/<user>/<repo>.git
git push -u origin main

The Novice Trap: SSL Verification Fails

If your local machine doesn’t trust your Let’s Encrypt cert yet (or if you are using self-signed certs), your git push might fail.

The Fix:

Ensure your domain is fully resolved in DNS. If you are on the same network as the server, you may need to add your domain to your local /etc/hosts file to bypass “hairpin NAT” issues.

Expanded Troubleshooting:

Step 1: Fire Up the Compose File

First, run your docker-compose.yml. This file is the “blueprint” for your infrastructure. Here is what is happening under the hood for a novice user:

Traefik as the Gateway: Instead of GitLab managing its own SSL, Traefik sits in front. It talks to Let’s Encrypt to get your HTTPS certificates automatically.
The External URL: In your config, external_url is set to https://your-domain.com. Even though Traefik handles the security, GitLab needs to know its public name to generate correct links for your repositories.
Internal Networking: You’ll notice nginx['listen_https'] = false and port 80. This tells GitLab to stay “simple” internally while Traefik handles the “secure” (HTTPS) traffic from the outside world.
Persistent Data: We map volumes (like /var/opt/gitlab) to your host machine. This ensures that if the container restarts, your code and users are still there.

Step 2: Run the Runner Setup Script

GitLab Runners are the “workers” that actually run your code tests and builds.

The setup script uses the new 2025 workflow. Gone are the days of old “registration tokens.” We now use Authentication Tokens (starting with glrt-) which are more secure and easier to manage across multiple machines.

When you run the registration command:

It connects to your new GitLab instance.
It identifies itself as a Docker Executor.
It binds to the docker.sock. This is high-value: it lets the runner spin up temporary containers to test your code in a clean environment every time.

GitLab no longer asks you to set a password on the first screen. For security, it generates a random one and hides it inside the container.

To find it, run: docker exec -it gitlab grep 'Password:' /etc/gitlab/initial_root_password.

Note: This file is deleted after 24 hours, so your first task should be changing the password in the User Settings.

Step 4: Create Your First Repo

Once you are in, click the “New Project” button and select “Create blank project.”

Visibility: Choose “Private” if you’re not ready for the world to see your code.
Initialize: You can initialize with a README to see it live immediately.

Step 5: Connect Your Code

To move an existing project into your new instance, use these standard Git commands:

Initialize local Git: git init (if you haven’t already).
Add your new home: git remote add origin https://your-gitlab-url.com/username/project.git.
Push everything: git push -u origin main.
